Grid cover telescope TLP 70 G, TLP 90 G and 120 G

TLP 70 G – Art. 319000

TLP 90 G – Art. 317000

TLP 120 G – Art. 319001

The manual telescopic luminaire hanger for the grid or maintenance ceiling

The grid ceiling telescope for mounting above a grid or maintenance ceiling serves the precise positioning of lighting, audio, and video equipment.

The vertical adjustment is done manually or by an external motor (drilling machine with torque limiter DWSE 6,3) A statically and dynamically self-locking gearing ensures a high safety level. The telescope is manufactured in a modular design, which makes it possible to adapt it to local conditions or customer requirements without any problem. The telescope has a very low overall height in the retracted state.

The aluminum profiles used with high mechanical precision combined with the wear-free plastic guides ensure a minimal radial clearance of <+ – 2 °. The standpipe has a diameter of 68mm. Two cable bobbins ensure an exact winding of the suspension elements. A DIN TV sleeve with d = 29mm serves as a load receptacle.

A guide roller Between the support rails of the grid cover ensures a safe and stable running of the light fixture.

The telescopes from the company MTS – Media Technical System meet the relevant safety regulations DGUV regulation 17 (formerly BGV C1, formerly VBG 70) as well as DIN 56950-2 (formerly DIN 15560)

Produkt Highlights
Technische Daten
Zubehör

The Highlights at a glance:
  • Payload: up to 60 kg
  • External drive by means of drill with torque limiter
  • Dynamically self-locking gearbox
  • Weight: approx. 30 kg
Bohrmaschiene_Teleskop_ 500x500

Technical Data:

  • xxx

Technische Zeichnung:

 DOWNLOAD Operating instructions, service manuals and programming files

Accessories
Bohrmaschiene_Teleskop_ 500x500

Art.Nr. 317.005 DSW 6,3 Motorantrieb für TLP Teleskope
